Metal Clad Cable with Aluminum Armor and Copper Conductors 250FT Coil R6843
Metal Clad Cable with Aluminum Armor and Copper Conductors 250FT Coil R6843
EASIER PULLS- U.S. Patent Pending armor is designed to reduce friction when pulling cable through metal studs and ceilings
NO NEED FOR NEW TOOLS- Works with the same tools and fittings you use with legacy cables
TIME SAVING- MC Glide can be pulled in half the time compared to traditional MC cable
COST REDUCTION- Because MC Glide is so much easier, your team can work faster and more efficiently
MINIMIZE DAMAGE TO STUDS- Less resistance means you won’t bend or knock down studs
Applications:
Commercial, industrial, multi-residential branch circuits and feeder wiring, services for power, lighting, control and signal circuits. Exposed or concealed, fished, surface mounted, embedded in plaster, environmental air-handling spaces, open or messenger supported aerial runs, dry locations, in hazardous locations to Class I & II Div. 2 and Class III, Div. 1 & 2 (per NEC Articles 501, 502, 503, 530), and in Places of Assembly Aluminum Interlocking Armor.
Construction:
- Aluminum armor
- UL Classified for Through-Wall Penetrations
- MC Lite is a traditional Type MC cable containing one or more copper grounding conductors; the armor is not an equipment grounding means
- Aluminum armored cables are RoHS Compliant
- Made in USA of US and/or imported materials
References & Ratings:
Armor: Interlocking Aluminum Strip
Conductors: Stranded Copper
Conductor Insulation: THHN/THWN
Maximum Temperature Rating: 90°C (dry)
Grounding: One grounding means – Insulated Green Grounding Conductor
Maximum Voltage Rating: 600V
References & Ratings:
- UL 83, 1479, 1569, 1581, 2556, File Reference E80042
- NEC 230.43, 300.22(C), 392, 396, 330, 501, 502, 503, 530, 504, 505, 518, 520, 530, 645
- Federal Specification A-A–59544 (formerly J-C–30B)
- Meets all applicable OSHA and HUD Requirements
- May be surface mounted, fished and/or embedded in plaster
- UL Classified 1, 2, and 3 hour through (Fire) penetration product, R–14141
- Environmental Air-Handling Space Installation per NEC 300.22(C)
- RoHS Compliant
- Made in USA of US and/or imported materials
